HQ--460DY Dry Imager

High‑resolution medical dry film printer for digital X‑ray imaging output.

Feature

• Produces sharp, high‑resolution images for X‑ray clinical diagnosis.
• Specially designed for medical digital X‑ray dry film printing.
• Stable performance, suitable for hospital radiology department use.

Technical Data

Print Technology	Direct thermal (dry, daylight-load film)
Spatial Resolution	320dpi (12.6 pixels/mm)
Throughput	14''×17'' ⩾ 50 sheets/h; 8''×10'' ⩾ 70 sheets/h
Grayscale Contrast Resolution	14 bits
Film Transferring Method	Rubbing
Film Tray	Two supply tray, 200-sheet capacity total
Film Sizes	8''×10'', 10''×12'', 11''×14'', 14''×17''
Applicable film	Medical Dry Thermal Film (blue or clear base)
Network Protocol	Standard DICOM 3.0 connection
Interface	10/100/1000 Base-T Ethernet (RJ-45)
Image Quality	Automatic calibration using built-in densitometer
Control Panel	Touch Screen, Online Display, Alert, Fault and Active
Power Supply	100-240VAC 50/60Hz 600W
Weight	50Kg
Operating Temperature	5℃-35℃
Storage Humidity	30%-85%
Storage Temperature	-22℃-50℃
Base Holding	Optional
